Widershine High-Resolution Imaging Sonar System Acoustic Equipment for Underwater
Widershine High-Resolution Imaging Sonar System Acoustic Equipment for Underwater
Precio habitual
$19,000.00 USD
Precio habitual
$25,000.00 USD
Precio de oferta
$19,000.00 USD
Precio unitario
por
No se pudo cargar la disponibilidad de retiro
Portable Dual-Frequency Imaging Sonar
It is used for real-time underwater imaging in complex environments such as rivers, lakes and seas. It can be equipped on various platforms (such as ROV, AUV, UUV, divers, etc.) to meet the needs of various underwater exploration, collision avoidance and construction operations.
Technical Specifications
|
Operating Frequency
|
750kHz / 1.2MHz
|
Range Resolution
|
4mm / 2.5mm
|
|
Physical Dimensions
|
124×113×62 mm
|
Detection Range
|
120m / 40m
|
|
Weight
|
1.1kg (air) / 0.48kg (water)
|
Blind Zone
|
0.1m
|
|
Operating Temperature
|
-5℃ to 35℃
|
Maximum Beams
|
512
|
|
Storage Temperature
|
-20℃ to 50℃
|
Continuous Operation Time
|
≥24h
|
|
Power Supply Requirement
|
DC18V-48V, power above 48W
|
Typical Power Consumption
|
25W
|
|
Horizontal Beam Width
|
130° / 80°
|
|
|
|
Vertical Beam Width
|
20° / 12°
|
|
|
|
Maximum Operating Depth
|
500m
|
|
|
